Giant Revolt 1 2026

Sizes XS, S, M, M/L, L, XL
Colours Alpine Green
Frame ALUXX-grade aluminum, 12x142mm thru-axle, disc, flip chip dropout
Fork Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Handlebar Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Grips cork tape with gel
Stem Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Seatpost Giant D-Fuse, alloy, 14mm offset
Saddle Giant Grit
Pedals PEDALS NOT SUPPLIED
Shifters Shimano CUES U6030, 2×10
Front Derailleur Shimano CUES U6030
Rear Derailleur Shimano CUES U6020
Brakes Shimano CUES U6030 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake LeversShimano CUES U6030 hydraulic
Cassette Shimano CS-LG300, 11×39
Chain KMC X11
Crankset Shimano FC-U6030-2, 32/46 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom BracketShimano, threaded
Rims Giant S-X2, alloy
Hubs Giant alloy, 12mm thru-axle
Spokes stainless
Tyres Giant CrossCut AT 2, 700x38c, tubeless
Extras tubeless prepared
Max Tyre Clearance53mm max tyre size in “long” flip chip position, 45mm max tyre size in “short” flip chip position with 1x drivetrains. Max tyre size with a 2x drivetrain is 45mm in the long position.
WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
